Product introduction
Teflon membrane folding filter is divided into two kinds of hydrophilic and hydrophobic
Consists of a polytetrafluoroethylene film and a polyeneene fitting (PP) or a soluble polytetrafluoroethylene fitting (PFA)
Excellent chemical stability, resistant to almost all organic and inorganic chemical corrosion
Has good heat resistance
Technical Data Sheet
| Accuracy (μm) | 0.01 (gas) | 0.2 (liquid) | 0.45 (liquid) |
| Blistering (Bar) | 2.2 | 2.2 | 1.2 |
| length | 5 "10" 20 "30" 40 " | Operating temperature | <90 ° C (PP case) |
| diameter | 2.75 " | Operating temperature | <150 ℃ (PFA case) |
| Filter material | Teflon | *** Great temperature resistance | <121 ° C (PP case) |
| Support material | Polypropylene / soluble polytetrafluoroethylene | *** Great temperature resistance | <180 ℃ (PFA case) |
| shell material | Polypropylene / soluble polytetrafluoroethylene | *** Big import pressure | 5.5bar (25 ° C) |
| Filtration area | > 0.6 square meters / 10 " | Suggested replacement cycle | <1 year or <50 steam sterilizations |
| Sterilization temperature | 121 ℃, 30min (50 times) | *** large differential pressure | 4.0bar (25 ° C) |
